Optical chopper OCV-6300F
Update: 2017/9/13 View:
- Brand: AVESTA
- Type: OCV-6300F
Introduction
An opto-mechanical modulator (chopper) is widely used in different optical experiments. It modulates different light sources with given frequency for their subsequent analysis. The built-in frequency counter allows precise selection of the chopping frequency without any external devices.
The joint use of the optical chopper with the lock-in amplifier greatly facilitates low-amplitude signal detection against high-level background noise.
Frequency range 7-6300 Hz *
Sync output *
High frequency stability *
Built-in frequency counter *
| OCV-6300F | ||
| Frequency range, Hz | 7-6300 | |
| Chopping frequency with 2-slot blade, Hz | 7-120 | |
| Chopping frequency with 10-slot blade, Hz | 40-600 | |
| Chopping frequency with 30-slot blade, Hz | 120-1900 | |
| Chopping frequency with 60-slot blade, Hz | 150-3700 | |
| Chopping frequency with 100-slot blade, Hz | 260-6300* | |
| Output sync signal level at BNC connector, V | +5 (50 ohm) | |
| Frequency setting accuracy, Hz | 1 | |
| Power supply (AC-DC adapter 12V, 0.35 A), V | 110-230 | |
| Power consumption, W | 4 | |
| Dimensions (WxLxH), mm | 87x104x148 | |
| * - the clear aperture with this blade is 1.5 mm | ||
The default supply package includes motor driver, power supply and one blade.
